8mm Diameter Stepper Motor With Worm Gearbox

The 8mm stepper motor with parallel output shaft gearbox is designed for miniature positioning systems, supporting precise step-by-step motion in compact electromechanical assemblies.

Get a Quote
  • 8mm Diameter Stepper Motor With Worm Gearbox Featured Image
Specs

Key Features

This model combines a micro stepper motor with a parallel output gearbox, focusing on controlled incremental movement rather than continuous rotation behavior.

  • Stepper motor structure supports discrete step positioning
  • Parallel output shaft enables straight-through mechanical layouts
  • Compact gearbox profile suitable for miniature mechanisms
  • Integrated motor and gearbox simplify alignment and installation
  • Designed for applications requiring repeatable positioning accuracy
technical Specs

Motors Specifications

Reduction Ratio 50 110 168 230 250 293 350 380
Gearbox length mm 9 9 9 9 9 9 9 9
Step angle °　 0.36 0.164 0.107 0.086 0.072 0.061 0.051 0.047
Pull in torque(500pps) g. cm 173 339 517 647 770 902 1078 1170
Rated speed(500pps) rpm 150 50 30 15 10 7.14 6 5.03

For additional customization or reference configurations, please feel free to contact us.

Why Choose us

SLW Motor Highlights

  • Positioning-Oriented Drive Design

    The stepper motor platform is suited for applications requiring controlled incremental motion rather than free rotation.

  • Compact Inline Integration

    Parallel output configuration supports clean mechanical routing in small assemblies.

  • Predictable Motion Control

    Stepper-based operation enables repeatable movement without complex feedback systems.

  • Designed for Miniature Indexing Systems

    This model is commonly applied in compact devices where size and positioning accuracy are key factors.

Custom

Beyond the Standard: Performance Customized

  • 01
    Step Angle and Drive Mode Matching
    Configuration can be reviewed to match required step resolution and control method.
  • 02
    Parallel Output Shaft Adaptation
    Output shaft length and end style can be adjusted for gears, pulleys, or direct coupling.
  • 03
    Gearbox Ratio Review
    Gearbox configuration can be evaluated to suit target indexing speed and torque needs.
  • 04
    Control Interface Integration
    Wiring orientation and connector options can be adapted to match control board layouts.
  • 05
    Application-Specific Positioning Needs
    Customization can be discussed based on overall motion control and indexing requirements.
  • Step Angle and Drive Mode Matching
  • Parallel Output Shaft Adaptation
  • Gearbox Ratio Review
  • Control Interface Integration
  • Application-Specific Positioning Needs

Custom Now

Related

Explore Our Motor

View All Products

FAQ

Frequently Asked Questions

For detailed selection guidance or project-specific requirements, please contact our team for further support.

What type of motion does this motor provide?
It provides step-by-step incremental motion rather than continuous rotation.
What voltage range does this motor support?
It is designed to operate within a 3V to 12V voltage range.
Is the gearbox supplied with the motor?
Yes. The motor and parallel output gearbox are supplied as an integrated assembly.
Is this suitable for precise positioning applications?
It is intended for compact systems requiring repeatable positioning accuracy.
Can this motor be customized for specific shaft or mounting needs?
Customization options are available depending on application requirements and production volume.
